البطاقة الذكيه والاكسس

Dim strNewLine As String
    Dim strNewTab As String

    Dim ss As String
    Dim s As String
    Dim bb As Boolean
    Dim ii As Integer

    Dim Proto As TxProtocol
    Dim Sharing As TxSharingMode
    Dim Closing As TxCardClosingMode
    Dim CardInit As TxCardInitializationMode
    Dim LogMode As TxEventsLoggingMode

    Dim Locked As Boolean
    Dim Connected As Boolean
    Dim CardReady As Boolean

    Dim ReadersList() As String
    Dim ReaderName
    Dim InfoLines() As String
    Dim InfoLine

    Dim VersionMajor As Integer
    Dim VersionMinor As Integer
    Dim VersionStr As String

Private Sub EnableCardReadyControls()
CardReady = SCardX_Easy.IsCardReady(RList.Text)

CommandRInfo.Enabled = Connected And CardReady And (Not Locked)
CommandCInfo.Enabled = Connected And CardReady And (Not Locked)
CommandATR.Enabled = Connected And CardReady And (Not Locked)
CommandReopen.Enabled = Connected And CardReady And (Not Locked)
CommandAPDU.Enabled = Connected And CardReady And (Not Locked)
CommandDATA.Enabled = Connected And CardReady And (Not Locked)

CommandOpenReader.Enabled = Connected And (Not CardReady)
CommandCloseReader.Enabled = Connected And CardReady And (Not Locked)
CommandReconnect.Enabled = Connected And CardReady And (Not Locked)
End Sub

Private Sub AddCommand(CommTarget As String, ComStr As String)
EventsList.AddItem "> " & ComStr & strNewTab & CommTarget
EventsList.Selected(EventsList.ListCount - 1) = True
End Sub

Private Sub AddLine(LineStr As String)
EventsList.AddItem "... " & strNewTab & LineStr
EventsList.Selected(EventsList.ListCount - 1) = True
End Sub

Private Sub AddEvent(EventSource As String, EventStr As String)
EventsList.AddItem "> " & EventStr & " :: " & EventSource
EventsList.Selected(EventsList.ListCount - 1) = True
End Sub

Private Sub MakeReadersList(ReadersNames As String)
RList.Clear
ReadersList = Split(ReadersNames, strNewLine, -1, 1)
ii = 0
For Each ReaderName In ReadersList
    ii = ii + 1
    If ReaderName <> "" Then
        RList.AddItem ReaderName
        End If
    Next
If (RList.ListCount > 0) Then RList.ListIndex = 0
EnableCardReadyControls
End Sub

Private Sub EnableControls()
Connected = (SCardX_Easy.ConnectionState = stServiceConnected)
RList.Enabled = Connected

CommandConnect.Enabled = Not Connected And (Not Locked)
CommandDisconnect.Enabled = Connected And (Not Locked)
CommandRefresh.Enabled = Connected And (Not Locked)

EnableCardReadyControls
End Sub

Private Sub ShowControls()
If (SCardX_Easy.VisibleToolBar) Then Check1.Value = Checked Else: Check1.Value = Unchecked
If (SCardX_Easy.VisibleStatusBar) Then Check2.Value = Checked Else: Check2.Value = Unchecked
If (SCardX_Easy.VisibleEventsHistory) Then Check4.Value = Checked Else: Check4.Value = Unchecked
If (SCardX_Easy.EventsHistoryEnabled) Then Check3.Value = Checked Else: Check3.Value = Unchecked
If (SCardX_Easy.SeparateReceivedBytes) Then Check9.Value = Checked Else: Check9.Value = Unchecked
If (SCardX_Easy.VisibleTrayIcon) Then Check10.Value = Checked Else: Check10.Value = Unchecked
If (SCardX_Easy.EventsLogging = xLog_AllEvents) Then Check8.Value = Checked Else: Check8.Value = Unchecked
End Sub

Private Sub Check1_Click()
SCardX_Easy.VisibleToolBar = (Check1.Value = Checked)
ShowControls
End Sub

Private Sub Check10_Click()
SCardX_Easy.VisibleTrayIcon = (Check10.Value = Checked)
ShowControls
End Sub

Private Sub Check2_Click()
SCardX_Easy.VisibleStatusBar = (Check2.Value = Checked)
ShowControls
End Sub

Private Sub Check3_Click()
SCardX_Easy.EventsHistoryEnabled = (Check3.Value = Checked)
ShowControls
End Sub

Private Sub Check4_Click()
SCardX_Easy.VisibleEventsHistory = (Check4.Value = Checked)
ShowControls
End Sub

Private Sub Check8_Click()
If (Check8.Value = Checked) Then LogMode = xLog_AllEvents Else LogMode = xLog_MostUsefulEvents
SCardX_Easy.EventsLogging = LogMode
ShowControls
End Sub

Private Sub Check9_Click()
SCardX_Easy.SeparateReceivedBytes = (Check9.Value = Checked)
ShowControls
End Sub

Private Sub Command1_Click()
SCardX_Easy.TrayIconMenuCreate (TryIconMenuItems.Text)
End Sub

Private Sub Command11_Click()
bb = (AutoOpenCheck.Value = Checked)
Proto = ProtoCombo.ListIndex
Sharing = SharingCombo.ListIndex
Closing = ClosingCombo.ListIndex
SCardX_Easy.SetPref_PCSC_OnCardDetect bb, Proto, Sharing, Closing
End Sub

Private Sub Command2_Click()
bb = SCardX_Easy.TrayIconMenuItemSetChecked(ItemID.Text, True)
End Sub

Private Sub Command3_Click()
bb = SCardX_Easy.TrayIconMenuItemSetChecked(ItemID.Text, False)
End Sub

Private Sub Command4_Click()
bb = SCardX_Easy.TrayIconMenuItemSetEnabled(ItemID.Text, True)
End Sub

Private Sub Command5_Click()
bb = SCardX_Easy.TrayIconMenuItemSetEnabled(ItemID.Text, False)
End Sub

Private Sub Command6_Click()
bb = SCardX_Easy.TrayIconMenuItemSetDefault(ItemID.Text, True)
End Sub

Private Sub Command7_Click()
bb = SCardX_Easy.TrayIconMenuItemSetDefault(ItemID.Text, False)
End Sub

Private Sub Command8_Click()
ss = SCardX_Easy.DES_DecryptString(KeyHEX.Text, DecrText.Text)
AddCommand "", "DES Decrypt String"
AddLine "Key HEX  : " & KeyHEX
AddLine "Encrypted data  : '" & DecrText.Text & "'"
AddLine "Decrypted data  : '" & ss & "'"
End Sub

Private Sub Command9_Click()
ss = SCardX_Easy.DES_EncryptString(KeyHEX.Text, EncrText.Text)
AddCommand "", "DES Encrypt String"
AddLine "Key HEX  : " & KeyHEX
AddLine "Text for encrypt  : '" & EncrText.Text & "'"
AddLine "Encrypted data    : " & ss
End Sub

Private Sub CommandAPDU_Click()
SW1SW2.Text = ""
DataOut.Text = ""
sss = SCardX_Easy.SendCardAPDU(RList.Text, Cla.Text, Ins.Text, P1_1.Text, P2_1.Text, P3_1.Text, Le_1.Text, DataIn.Text, s, ss)
SW1SW2.Text = s
DataOut.Text = ss
End Sub

Private Sub CommandATR_Click()
AddCommand "", "Get Card ATR"
ss = SCardX_Easy.GetCardATR(RList.Text)
EventsList.AddItem ss
EventsList.Selected(EventsList.ListCount - 1) = True
End Sub

Private Sub CommandCInfo_Click()
AddCommand "", "Get Card Info"
If (Check6.Value = Checked) Then ss = SCardX_Easy.GetCardInfoFmt(RList.Text) Else ss = SCardX_Easy.GetCardInfo(RList.Text)
InfoLines = Split(ss, strNewLine, -1, 1)
ii = 0
For Each InfoLine In InfoLines
    ii = ii + 1
    If InfoLine <> "" Then
        s = InfoLine
        EventsList.AddItem s
        End If
    Next
EventsList.Selected(EventsList.ListCount - 1) = True

End Sub

Private Sub CommandCloseReader_Click()
SCardX_Easy.CloseReader (RList.Text)
End Sub

Private Sub CommandConnect_Click()
SCardX_Easy.SmartCardService = srv_MS_PCSC_SCard_Service
SCardX_Easy.ConnectionState = stServiceConnected
End Sub

Private Sub CommandDATA_Click()
ReceivedBuffer.Text = ""
s = SCardX_Easy.SendCardDATA(RList.Text, SendBuffer.Text)
ReceivedBuffer.Text = s
End Sub

Private Sub CommandDisconnect_Click()
SCardX_Easy.ConnectionState = stServiceNotConnected
SCardX_Easy.SmartCardService = srv_Not_Defined
End Sub

Private Sub CommandErrorLookUp_Click()
AddCommand TextELookUp.Text, "ErrorLookUp"
ss = SCardX_Easy.LookUpError(TextELookUp.Text)
EventsList.AddItem ss
EventsList.Selected(EventsList.ListCount - 1) = True
End Sub

Private Sub CommandOpenReader_Click()
SCardX_Easy.OpenReader (RList.Text)
End Sub

Private Sub CommandReconnect_Click()
Proto = ComboReconnectProto.ListIndex + 1
Sharing = ComboReconnectShare.ListIndex
CardInit = ComboReconnectInit.ListIndex
SCardX_Easy.ReconnectReader RList.Text, Proto, Sharing, CardInit
End Sub

Private Sub CommandRefresh_Click()
MakeReadersList (SCardX_Easy.GetReadersList)
End Sub

Private Sub CommandReopen_Click()
SCardX_Easy.ReopenReader (RList.Text)
End Sub

Private Sub CommandRInfo_Click()
AddCommand "", "Get Reader Info"
If (Check5.Value = Checked) Then ss = SCardX_Easy.GetReaderInfoFmt(RList.Text) Else ss = SCardX_Easy.GetReaderInfo(RList.Text)
InfoLines = Split(ss, strNewLine, -1, 1)
ii = 0
For Each InfoLine In InfoLines
    ii = ii + 1
    If InfoLine <> "" Then
        s = InfoLine
        EventsList.AddItem s
        End If
    Next
EventsList.Selected(EventsList.ListCount - 1) = True
End Sub

Private Sub CommandStateLookUp_Click()
AddCommand TextSLookUp.Text, "StateLookUp"
ss = SCardX_Easy.LookUpReaderState(TextSLookUp.Text)
InfoLines = Split(ss, strNewLine, -1, 1)
ii = 0
For Each InfoLine In InfoLines
    ii = ii + 1
    If InfoLine <> "" Then
        s = InfoLine
        EventsList.AddItem s
        End If
    Next
EventsList.Selected(EventsList.ListCount - 1) = True
End Sub

Private Sub Form_Load()
strNewLine = Chr(13) & Chr(10)
strNewTab = Chr(9)

Locked = False
Connected = False
CardReady = False

ProtoCombo.Clear
ProtoCombo.AddItem "Autodetect"
ProtoCombo.AddItem "T0"
ProtoCombo.AddItem "T1"
ProtoCombo.AddItem "RAW"
ProtoCombo.AddItem "Undefined"
ProtoCombo.Text = "Autodetect"

SharingCombo.Clear
SharingCombo.AddItem "Share Reader"
SharingCombo.AddItem "Exclusive Use"
SharingCombo.AddItem "Direct Reader Control"
SharingCombo.Text = "Share Reader"


ClosingCombo.Clear
ClosingCombo.AddItem "Leave Card"
ClosingCombo.AddItem "Reset Card"
ClosingCombo.AddItem "Unpower Card"
ClosingCombo.AddItem "Eject Card"
ClosingCombo.Text = "Reset Card"


ComboReconnectProto.Clear
ComboReconnectProto.AddItem "T0"
ComboReconnectProto.AddItem "T1"
ComboReconnectProto.ListIndex = 0

ComboReconnectShare.Clear
ComboReconnectShare.AddItem "Share Reader"
ComboReconnectShare.AddItem "Exclusive Use"
ComboReconnectShare.ListIndex = 0

ComboReconnectInit.Clear
ComboReconnectInit.AddItem "Leave Card"
ComboReconnectInit.AddItem "Reset Card  ( Warm Reset )"
ComboReconnectInit.AddItem "Unpower Card  ( Cold Reset )"
ComboReconnectInit.ListIndex = 1

ii = 0
EventsList.Clear

SCardX_Easy.ActivePage = apStates
SCardX_Easy.VisibleStatusBar = True
SCardX_Easy.VisibleToolBar = False
SCardX_Easy.VisibleEventsHistory = True

VersionMajor = SCardX_Easy.VersionMajor
VersionMinor = SCardX_Easy.VersionMinor
Label1.Caption = SCardX_Easy.Version

SCardX_Easy.SmartCardService = srv_MS_PCSC_SCard_Service
SCardX_Easy.ConnectionState = stServiceConnected
ShowControls
EnableControls

TryIconMenuItems.Text = "ID_1=TryIcon Menu Item 1" & strNewLine & "----" & strNewLine & "ID_2=TryIcon Menu Item 2" & strNewLine & "ID_3=TryIcon Menu Item 3"
SCardX_Easy.TrayIconMenuCreate (TryIconMenuItems.Text)
bb = SCardX_Easy.TrayIconMenuItemSetDefault("ID_1", True)
bb = SCardX_Easy.TrayIconMenuItemSetChecked("ID_2", True)
End Sub

Private Sub Form_Unload(Cancel As Integer)
SCardX_Easy.Finalize
End Sub

Private Sub RList_Click()
CardReady = SCardX_Easy.IsCardReady(RList.Text)
EnableCardReadyControls
End Sub

Private Sub SCardX_Easy_OnCardDetected(ReaderName As String)
AddEvent ReaderName, "OnCardDetected"
EnableCardReadyControls
End Sub

Private Sub SCardX_Easy_OnCardInvalid(ReaderName As String)
AddEvent ReaderName, "OnCardInvalid"
EnableCardReadyControls
End Sub

Private Sub SCardX_Easy_OnCardReady(ReaderName As String, ATR As String, ProtocolValue As Long, Protocol As String)
AddEvent ReaderName, "OnCardReady"
AddLine "ATR     " & " :: " & ATR
AddLine "Protocol" & " :: " & Protocol
EnableCardReadyControls
End Sub

Private Sub SCardX_Easy_OnCardWait(ReaderName As String)
AddEvent ReaderName, "OnCardWait"
EnableCardReadyControls
End Sub

Private Sub SCardX_Easy_OnConnected(Service As Long)
EnableControls
End Sub

Private Sub SCardX_Easy_OnDataSent(ReaderName As String, SentDataBuffer As String, ReceivedDataBuffer As String)
AddEvent ReaderName, "OnDataSent"
AddLine "Sent Data     :: " & SentDataBuffer
AddLine "Received Data :: " & ReceivedDataBuffer
End Sub

Private Sub SCardX_Easy_OnDisconnected()
EnableControls
End Sub

Private Sub SCardX_Easy_OnERROR(ErrorSource As String, ErrorCode As Long, ErrorString As String)
AddEvent ErrorSource, "### ERROR"
AddLine "Error Code    :: " & ErrorCode
AddLine "Error String  :: " & ErrorString
End Sub

Private Sub SCardX_Easy_OnHistoryEvent(EventID As Long, EventSource As String, EventBody As String, EventValue As String, EventTime As String)
'AddEvent "", "OnHistoryEvent"
'AddLine "ID     :: " & EventID
'AddLine "Event  :: " & EventBody
'AddLine "Value  :: " & EventValue
'AddLine "Source :: " & EventSource
'AddLine "Time   :: " & EventTime
End Sub

Private Sub SCardX_Easy_OnLock(Message As String)
Locked = True
EnableControls
End Sub

Private Sub SCardX_Easy_OnReaderAdded(ReaderName As String)
AddEvent ReaderName, "OnReaderAdded"
End Sub

Private Sub SCardX_Easy_OnReaderClosed(ReaderName As String)
AddEvent ReaderName, "OnReaderClosed"
EnableCardReadyControls
End Sub

Private Sub SCardX_Easy_OnReaderOpened(ReaderName As String)
AddEvent ReaderName, "OnReaderOpened"
EnableCardReadyControls
End Sub

Private Sub SCardX_Easy_OnReaderRemoved(ReaderName As String)
AddEvent ReaderName, "OnReaderRemoved"
End Sub

Private Sub SCardX_Easy_OnReadersList(ReadersList As String)
MakeReadersList (ReadersList)
End Sub

Private Sub SCardX_Easy_OnReaderStateChanged(ReaderName As String, ReaderState As Long, ReaderStateHex As String, ReaderStateLookup As String)
If (Check7.Value = Checked) Then
    AddEvent ReaderName, "OnReaderStateChanged"
    ss = ReaderStateLookup
    InfoLines = Split(ss, strNewLine, -1, 1)
    ii = 0
    For Each InfoLine In InfoLines
        ii = ii + 1
        If InfoLine <> "" Then
            s = InfoLine
            AddLine s
            End If
        Next
    End If
End Sub

Private Sub SCardX_Easy_OnTrayIconDblClick()
AddEvent "", "OnTrayIconDblClick"
End Sub

Private Sub SCardX_Easy_OnTrayIconMenuItem(ItemID As String, IsChecked As Boolean, IsEnabled As Boolean, IsDefault As Boolean, Caption As String)
AddEvent ItemID, "OnTrayIconMenuItem"
AddLine "Caption :: " & Caption
AddLine "Checked :: " & IsChecked
AddLine "Enabled :: " & IsEnabled
AddLine "Default :: " & IsDefault

bb = Not IsChecked
If (ItemID = "ID_2") Then b = SCardX_Easy.TrayIconMenuItemSetChecked("ID_2", bb)
End Sub

Private Sub SCardX_Easy_OnUnlock()
Locked = False
EnableControls
End Sub
